Know your WallFi®

The WallFi® WAP-01 is ideal for converting an exixting wired Ethernet socket to a wireless access Point.



I sell on Tindie

I sell on Tindie

Know More

Features

Power Supply
Design
dimension
wifi
repeater
poe

Specification

General

Standards IEEE 802.11n, 802.11b, 802.11g
Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Port One 10/100Mbps LAN port
Cabling Type 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX: UTP category 5, 5e cable (maximum 100m)

Power 110V – 220V/0.5A, PoE 5V – 24VDC/0.5A
Dimensions (L x W x H) 80mm x 80mm x 12mm
Safety & Emissions FCC , CE

Wireless

Frequency Band 2.4~2.4835GHz
Radio Data Rate 11n: up to 150Mbps (Automatic)

11g: 54/48/36/24/18/12/9/6M (Automatic)

11b: 11/5.5/2/1M (Automatic)

Frequency Expansion DSSS (Direct Sequence Spread Spectrum)
Modulation DBPSK, DQPSK, CCK, 16-QAM, 64-QAM, BPSK, QPSK
Security 64/128/152-bit WEP, WPA/WPA2, WPA2-PSK/WPA-PSK
Sensitivity @PER 135M: -70dBm@10% PER

65M: -73dBm@10% PER

54M: -76dBm@10% PER

Mode AP Mode, Repeater Mode, Bridge Mode, Client Mode

Environmental and Physical

Temperature Operating : 0℃~40℃ (32℉~104℉)
Storage: -40℃~70℃(-40℉~158℉)
Humidity Operating: 10% – 90% RH, Non-condensing
Storage: 5% – 90% RH, Non-condensing
